OIL EXPELLER

Item Code: Seco - 120

Oil Expeller Manufacturer India, Oil Screw Press Exporter India, 120, Ludhiana, Punjab, India.

Our Model Seco120 is having  a capacity of 11 Ton to 12 Ton. Seco - 120 is a cost-effective solution with moderate crushing capacity. These expellers require minimum maintenance and easy to operate. At the same time designed and developed using advanced technology, the plant is energy efficient as well. Compact and easy-to-maintain Seco - 120 is made of high quality material. It is designed as per international quality standards to ensure energy efficiency, higher output and continuous production.

Features:

  • Reduction Gear Box with Spur Gears.
  • The gear box is very properly machined & checked with latest equipment for better and long life of parts.
  • Steel Fabricated chamber.
  • Case hardened worm assembly.
  • Hard faced worm assembly (optional).
  • Less Space Required.
  • Worm assembly can be easily replaced without wasting of any time.
  • Superior quality of oil & cake.
  • Cast Iron Bodies.
  • Steel Fabricated Base.
  • Maintenance required is less & easy.
Specification
Power Consumption: 3-Phase 40 H.P to 50 H.P. Motor.
Feeding Drum: Single Stage or Double stage with & without heating arrangement ( As Required).
Capacity

11 Ton to 12 Ton per 24 Hours (458Kg. to 500Kg./Per Hour)
(Capacity varies with material density & quantity of oil in it.)




Oil Expeller Manufacturer India, Oil Screw Press Exporter India, 120, Ludhiana, Punjab, India.
